QY型起重机用硬齿面减速器

发布时间:2020-07-06 人气:1061 所属分类:QY型起重机用硬齿面减速器 立即咨询

一、QY型起重机用硬齿面减速器

Hard tooth face decelerator for QY type hoist

1.减速器的分类、应用范围Classification and application scope of decelerator

QY型系列减速器包括QYS型(三支点)和QYD型(底座式)两个系列起重机用硬齿面减速器。它有三级,四级和三四级结合型三种,其结构简图见图1。

QY series decelerator includes hard tooth face decelerator for type QYS (3-supporting- point) and type QYD (pedestal type) hoists. It has 3-step, 4 step and 3 and 4 combined type, see figure 1 for structural diagram.


此减速器主要用于起重机各有关机构,也可用于运输、冶金,矿山,化工及轻工等机械设备的传动中。其工作条件为:

1)齿轮圆周速度不大于20m/s;

2)高速轴转速不大于1500r/min;

3)工作环境温度为-40'C ~ +45'C;

4)可正反两向运转。

This decelerator is mainly used for each of related mechanism on the hoist, also for the transmission of mechanical equipment in transportation, meallurgy, mining, chemical industry, and light industry with working condition as follows:

1) Peripheral speed of the gear wheel does not exceed 20m/s;

2) Rotating speed of high speed shaft does not exceed 1500r/min;

3) Working ambient temperature is -40'C ~ +45'C ;

4) Both forward and backward rotation are available.
